Refrigerator Service ManualN611v, N811v Models
FAULT CODES
The refrigerator is not cooling if the indicator light is either on solid red or fl ashes on red.
NOTE
Light Indicator Possible Cause Action to Take
Green, flashes off once every 20 sec-
onds
The refrigerator is operating on AC
electric power. The thermister sensed
inoperable, so temperature is being
controlled by backup operating system.
■ Refer to "Thermister Fault" on page
15.
Amber, flashes off once every 20 sec-
onds.
The refrigerator is operating on propane
gas. The thermister sensed inoperable,
so temperature is being controlled by
backup operating system.
■ Refer to "Thermister Fault" on page
15.
Red, on solid. 120VAC power not available. Refrigera-
tor defaulted to propane gas operation,
but did not establish a flame (gas lock-
out).
■ Refer to "Solid Red Indicator Light"
on page 13.
Red, flashes on two (2) times every five
(5) seconds.
This is a fault within the refrigerator
controls.
■ Refer to "Fault / Flash Pattern 2
Service Error" on page 14.
Red, flashes on three (3) times every
five (5) seconds.
The temperature high limit switch is
open.
■ Refer to "Fault / Flash Pattern 3
Open High Limit" on page 14.
Red, flashes on four (4) times every five
(5) seconds.
This is a problem with the AC heater
circuit.
■ Refer to "Fault / Flash Pattern 4
AC Relay Error" on page 14.
Red, flashes on five (5) times every five
(5) seconds.
A flame is present at the burner when
there should none.
■ Refer to "Fault / Flash Pattern 5
Flame Should Not Be On" on page
14.
Red, flashes on eight (8) times every
five (5) seconds.
The DC voltage to the refrigerator is too
low to support cooling when operating
on propane gas.
■ Refer to "Fault / Flash Pattern 8
LOW DC (1) Error" on page 15.
Red, flashes on nine (9) times every five
(5) seconds.
The DC voltage to the refrigerator is too
low.
■ Refer to "Fault / Flash Pattern 9
LOW DC (2) Error" on page 15.
