Refrigerator Service ManualN611v, N811v Models
SPECIFICATIONS
N611v / N811v - Electronic
• Push Button - On/Off
• LED Indicator Lights
• Self-Diagnostic with Fault Indicators
• 2-Way Operation
Rough opening dimensions (H x W x D)
N611v ---------------------------------------------------------------------------------------------------- 52 7/8 in. x 23 1/2 in. x 24 in.
N811v ---------------------------------------------------------------------------------------------------- 59 7/8 in. x 23 1/2 in. x 24 in.
Decorative panels dimensions
Thickness ------------------------------------------------------------------------------------------------------------------------- 3/16 in.
Freezer door (H x W, both models) ----------------------------------------------------------------15 11/16 in. x 21 19/32 in.
Upper panel ---------------------------------------------------------------------------------------------- 15 11/16in. x 21 19/32in.
Fresh food compartment (H x W)
N611v --------------------------------------------------------------------------------------------------- 32 25/32 in. x 21 19/32 in.
N811v ---------------------------------------------------------------------------------------------------- 39 25/32 in. x 21 19/32 in.
DC power
DC input voltage requirements --------------------------------------------------------------------------- 10.5VDC to 15.4VDC
DC Fuse, F1 on Power Board --------------------------------------------------------Automotive Blade, Type APR-5A-Tan
Divider Heater ------------------------------------3.1W/12VDC, (43Ω to 50Ω), Current ≈ 240mA to 279mA @ 12VDC
Gas Valve ------------------------------- 1.75W/12VDC, (74Ω to 92Ω), Current ≈ 130mA to 162mA @ 12VDC
Interior Light -------------------------------------------------GE #214, Miniature Automotive Light Bulb, ½ A @ 13.5VDC
AC power
AC input voltage requirements ------------------------------------------------------------------------------108VAC to 132VAC
AC Fuse, F2 on Power Board ------------------------- AGC Series, 8A, Fast Acting, Glass Tube (1/4 in. x 1-1/4 in.)
AC Heater--------------------------------------------- 300W/120VAC, (46Ω to 51Ω), Current ≈ 2.3A to 2.6A @ 120VAC
LP gas (propane)
Operating pressure (Input pressure to gas valve) -----------------------------------------------------10.5 to 11.5 in. W.C.
Burner rating (Heat output) --------------------------------------------------------------------------- 1420 Btu/h @ 11 in. W.C.
Burner orifi ce size -----------------------------------------------------------------------------------------------------------------LP15
Gas ignition ------------------------------------------------------------------------------------------ Electronic with fl ame sensing
Electrode tip-to-burner gap -------------------------------------------------------------------------------------------1/8 to 3/16 in.
Off-level operating limits
Side-to-side------------------------------------------------------------------------------------------------------3 degrees-maximum
Front-to-back ----------------------------------------------------------------------------------------------------6 degrees-maximum
Temperature Sensor ---------------------------------------- ---------- Thermistor, Fin mounted (10th fi n from the right)
