N611v, N811v ModelsRefrigerator Service Manual
About this Manual
This service manual provides maintenance, diagnostic, and
repair information for NORCOLD
®
models N611v, N811v
gas absorption refrigerators. It is a reference tool designed
for technicians who are knowledgeable in the theory and
operation of gas/electric absorption refrigerators, liquefi ed
petroleum (LP) gas–propane–systems, and AC/DC electrical
systems as installed in a variety of recreational vehicles (RV).
All information, illustrations, and specifi cations contained in
this publication are based on the latest product information
available at the time of publication. NORCOLD
®
reserves the
right to make changes at any time without notice.
Model Identifi cation
Models N611v and N811v are 2-way refrigerators that operate
on AC power or LP gas.
Letter(s) appended to the model number identify factory
installed accessories. See Fig. 1.
Information Label
The information label is located in the upper right corner of the
fresh food compartment just below the divider. See Fig. 1. The
label provides the following information:
• Serial number.
• Model number.
• LP gas (propane) pressure.
• Btu/h.
• AC voltage and amperage.
• DC voltage and amperage.
• Design certifi cation.
• Vent kit requirement.
INTRODUCTION
Certifi cation and Code Requirements
NORCOLD
®
N611v, N811v gas/electric absorption refrigerators
are certifi ed under the latest edition of ANSI Z21.19B
standards for installation in mobile homes or recreational
vehicles, and with the Canadian Standards Association CAN/
CGA-1.4-M94.
Electrical components are
compliant.
About Installation
Refrigerator installation must conform with the N611v, N811v
Installation Manual for the NORCOLD
®
limited warranty to be
in effect. Installation must also comply with applicable local
codes and standards set by the relevant certifi cation agency.
Replacement Parts
Use only authorized NORCOLD
®
replacement parts.
Generic parts do not meet NORCOLD
®
specifi cations for
safety, reliability, and performance. The use of unauthorized
aftermarket or generic replacement parts voids the
refrigerator's limited warranty coverage.
Technical Assistance
If unable to resolve technical issues using the information
provided in this manual, technical support is available through
NORCOLD
®
Customer Service Center:
Telephone: 1-800-444-7210.
Fax: 1-734-769-2332
World Wide Web: www.norcold.com.
The following information is required to process technical
support requests; refer to the following page:
• Refrigerator Model Number
• Refrigerator Serial Number
• Refrigerator Cooling Unit Serial Number
• Recreational Vehicle (RV) Make/Model/Year
