Product information
Cu 330 Split and Cu 450 Split are our two split units, with capacity of 4,500 litres and 10,000
litres respectively. They are designed for chilling food for use in private households. The correct
temperature in the cold room will depend on correct construction and insulation.
The warm and cold elements of split units are separate. The cold element is installed in the
cold room and consists of: evaporator, fan, thermostat, capillary tubes, filter and light fitting
with switches. The warm element is installed in the machinery compartment and consists of:
refrigeration compressor, condenser, fan, electrical cabinet and defrosting timer. There are several
reasons why the warm element should not be installed in an adjacent room: heat emission, lack of
space, aesthetic grounds etc.
The units require a power supply of 220-240VAC 50 Hz and must be connected to an earthed
min.10A mains socket. The power cable is connected to the condenser. If the cable is not long
enough (2.7m) call an electrician to install a socket closer. The mains socket must be easily
accessible for installation/service. The warm element can be located up to 10m pipe length from
the cold room, and the two parts must be connected by copper pipe and electric cable. The mains
socket must be easily accessible for installation/service.
It is essential that there is sufficient ventilation around the warm element in the machinery
compartment. Ambient temperature on the warm side outside the cold room must always be
higher than inside, but must not exceed an average temperature of 27 °C.
Scandinavian Appliances AS also supplies other products that you need for a self-build cold room.
Important information
Scandinavian Appliances AS consumer products are sold for normal use in private households.
Split units must only be installed by a refrigeration engineer. To ensure correct use and thereby
extend the product service life, please read these instructions carefully. The manufacturer will not
assume liability for any damage resulting from non-compliance with the instructions. The product
will require maintenance even in normal use, plus replacement of components which are worn
out can be necessary. These are not covered during the warranty period but are covered by the
guarantee in accordance with the Sale of Goods Act.
Other authorities can apply regulations for e.g. lighting, alarm and the like for installation. The
electrical safety of the appliance is only guaranteed when it is installed in accordance with the
regulations and supplied with the prescribed voltage.
Never allow the unit to be permanently connected via an extension lead. Disconnect plug when
cleaning.
The appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Data plate with serial number is located on the front of the condenser and at the right side of the
condenser element. Always state the serial number when contacting the service company or the
manufacturer. Repairs must only be made by qualified personnel.
Scandinavian Appliances AS disclaims all liability for typographical errors in these instructions and
reserves the right to alter the product specifications.
