NORDAC FLEX (SK 200E ... SK 235E) – Users Manual for Frequency Inverters
138 BU 0200 en-3118
41 =
… 59
Reserved, POSICON
60 =
R stator ident
Stator resistance determined by means of measurement (P220)
61 =
R rotor ident
the rotor resistance determined by measurement ((P220) Function 2)
62 =
L stray stator ident
the stray inductance determined by measurement ((P220)
Function 2)
63 =
L stator ident
the inductance determined by measurement ((P220) Function 2)
65 = Reserved
Pos: 29 6 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par amet er/ Par amet erau fli st ung (P 000 .. .)/P 000- P099 /Par amet er P002 – Display-F a kt or @ 0\mod_1327573818457_388.docx @ 7409 @ @ 1
P002
Display factor
(Display factor)
S
0.01 ... 999.99
{ 1.00 }
The selected operating value in parameter P001 >Select of display< is multiplied with the scaling
factor in P000 and displayed in >Operating parameter display<.
It is therefore possible to display system-specific operating such as e.g. the throughput quantity
Pos: 29 7 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par amet er/ Par amet erau fli st ung (P 000 .. .)/P 000- P099 /Par amet er P003 – S uper vis or-Code [SK 1x0E, SK 2xxE, SK 2xxE-FDS] @ 2\mod_1346931544673_388.docx @ 42130 @ @ 1
P003 Supervisor code
(Supervisor code)
0 ... 9999
{ 1 }
0 =
The supervisor parameters and groups P3xx/P6xx are not visible, otherwise all.
1 =
All parameters are visible, except groups P3xx and P6xx.
2 =
All parameters are visible, except group P6xx.
3 =
All parameters are visible.
4 =
... 9999, only parameters P001 and P003 are visible.
Information
Display via NORDCON
If parameterisation is carried out with the NORDCON software, the settings 4 ... 9999 the
settings are as for the 0 setting. Settings 1 and 2 behave like setting 3.
