5 Parameter
BU 0200 en-3118 147
0 =
No change
1 =
No motor: In this setting, the FI operates without current control, slip compensation and
pre-magnetising time, and is therefore not recommended for motor applications. Possible
applications are induction furnaces or other applications with coils and transformers. The
following motor data is set here: 50.0 Hz / 1500 rpm / 15.0 A / 400 V / 0.00 kW / cos
ϕ
=0.90 / Stern / R
S
0.01
Ω
/ I
LEER
6.5 A
2 =
0.25kW 230V
32 =
4.0 kW 230V
62 =
90.0 kW 400V
92 =
1.00kW 115V
3 =
0.33PS 230V
33 =
5.0 PS 230V
63 =
120.0 PS 460V
93 =
4.0 PS 230V
4 =
0.25kW 400V
34 =
4.0 kW 400V
64 =
110.0 kW 400V
94 =
4.0 PS 460V
5 =
0.33PS 460V
35 =
5.0 PS 460V
65 =
150.0 PS 460V
95 =
0.75kW 230V 80T1/4
6 =
0.37kW 230V
36 =
5.5 kW 230V
66 =
132.0 kW 400V
96 =
1.10kW 230V 90T1/4
7 =
0.50PS 230V
37 =
7.5 PS 230V
67 =
180.0 PS 460V
97 =
1.10kW 230V 80T1/4
8 =
0.37kW 400V
38 =
5.5 kW 400V
68 =
160.0 kW 400V
98 =
1.10kW 400V 80T1/4
9 =
0.50PS 460V
39 =
7.5 PS 460V
69 =
220.0 PS 460V
99 =
1.50kW 230V 90T3/4
10 =
0.55kW 230V
40 =
7.5 kW 230V
70 =
200.0 kW 400V
100 =
1.50kW 230V 90T1/4
11 =
0.75PS 230V
41 =
10.0 PS 230V
71 =
270.0 PS 460V
101 =
1.50kW 400V 90T1/4
12 =
0.55kW 400V
42 =
7.5 kW 400V
72 =
250.0 kW 400V
102 =
1.50kW 400V 80T1/4
13 =
0.75PS 460V
43 =
10.0 PS 460V
73 =
340.0 PS 460V
103 =
2.20kW 230V 100T2/4
14 =
0.75kW 230V
44 =
11.0 kW 400V
74 =
11.0 kW 230V
104 =
2.20kW 230V 90T3/4
15 =
1.0 PS 230V
45 =
15.0 PS 460V
75 =
15.0 PS 230V
105 =
2.20kW 400V 90T3/4
16 =
0.75kW 400V
46 =
15.0 kW 400V
76 =
15.0 kW 230V
106 =
2.20kW 400V 90T1/4
17 =
1.0 PS 460V
47 =
20.0 PS 460V
77 =
20.0 PS 230V
107 =
3.00kW 230V 100T5/4
18 =
1.1 kW 230V
48 =
18.5 kW 400V
78 =
18.5 kW 230V
108 =
3.00kW 230V 100T2/4
19 =
1.5 PS 230V
49 =
25.0 PS 460V
79 =
25.0 PS 230V
109 =
3.00kW 400V 100T2/4
20 =
1.1 kW 400V
50 =
22.0 kW 400V
80 =
22.0 kW 230V
110 =
3.00kW 400V 90T3/4
21 =
1.5 PS 460V
51 =
30.0 PS 460V
81 =
30.0 PS 230V
111 =
4.00kW 230V 100T5/4
22 =
1.5 kW 230V
52 =
30.0 kW 400V
82 =
30.0 kW 230V
112 =
4.00kW 400V 100T5/4
23 =
2.0 PS 230V
53 =
40.0 PS 460V
83 =
40.0 PS 230V
113 =
4.00kW 400V 100T2/4
24 =
1.5 kW 400V
54 =
37.0 kW 400V
84 =
37.0 kW 230V
114 =
5.50kW 400V 100T5/4
25 =
2.0 PS 460V
55 =
50.0 PS 460V
85 =
50.0 PS 230V
115 =
26 =
2.2 kW 230V
56 =
45.0 kW 400V
86 =
0.12kW 115V
116 =
27 =
3.0 PS 230V
57 =
60.0 PS 460V
87 =
0.18kW 115V
117 =
28 =
2.2 kW 400V
58 =
55.0 kW 400V
88 =
0.25kW 115V
118 =
29 =
3.0 PS 460V
59 =
75.0 PS 460V
89 =
0.37kW 115V
119 =
30 =
3.0 kW 230V
60 =
75.0 kW 400V
90 =
0.55kW 115V
120 =
31 =
3.0 kW 400V
61 =
100.0 PS 460V
91 =
0.75kW 115V
121 =
Pos: 33 2 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 ...) /P200- P299 /Para meter P201 – Motor Nennfrequenz @ 0\mod_1327588385923_388.docx @ 7884 @ @ 1
P201
Nominal motor frequency
(Nominal motor frequency)
S P
10.0 ... 399.9 Hz
{ see information }
The motor nominal frequency determines the V/f break point at which the FI supplies the nominal
voltage (P204) at the output.
Information
Default setting
The default setting is dependent upon the FI nominal power and the setting in P200.
Pos: 33 3 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P2 00-P2 99/Par amet er P202 – Motor N e nndre hz ahl @ 0\ mod_1327588441470_388.docx @ 7907 @ @ 1
P202
Nominal motor speed
(Nominal motor speed)
S P
150 ... 24000 rpm
{ see information }
The nominal motor speed is important for the correct calculation and control of the motor slip and
the speed display (P001 = 1).
Information
Default setting
The default setting is dependent upon the FI nominal power and the setting in P200.
Pos: 33 4 /Allg emein/ Allg emeing ültig e Mod ule/---------Sei tenumbr uch ko mpakt --------- @ 13\mod_1476369695906_0.docx @ 2265495 @ @ 1
