6 Operating status messages
BU 0200 en-3118 229
Pos: 656 /A nleit ung en/El e ktr onik /FU und Star ter /6. M eldung en zu m B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Fehl er E0 10 [ SK 1 80E/SK 2 xxE/SK2xxE-FD S] @ 2\mod_1347453316597_388.docx @ 46601 @ @ 1
E010
10.0 Bus Timeout
Telegram time-out / Bus off 24V int. CANbus
• Data transfer is faulty. Check P513.
• Check physical bus connections
• Check bus protocol program process.
• Check Bus Master.
• Check 24V supply of internal CAN/CANopen Bus.
• Node guarding error (internal CANopen)
• Bus Off error (internal CANbus)
10.2 Bus Timeout Option
Telegram timeout
• Telegram transfer is faulty.
• Check physical bus connections
• Check bus protocol program process.
• Check Bus Master.
• PLC is in the "STOP" or "ERROR" state.
10.4 Init error Option
Initialisation error in bus module
• Check Bus module current supply.
• DIP switch setting of a connected I/O extension
module is incorrect
10.1 System error option
System error bus module
• Further details can be found in the respective
additional bus instructions.
I/O extension:
• Incorrect measurement of the input voltage or
undefined provision of the output voltage due to error
in reference voltage generation.
• Short circuit at analogue output
10.3
10.5
10.6
10.7
10.9 Module missing / P120
The module entered in parameter (P120) is not available.
• Check connections
