6 Operating status messages
BU 0200 en-3118 231
Pos: 66 1 /Anlei tung en/El ektr onik/FU und St art er/6 . M eld ung en zu m B etri ebsz ust a nd/S tör meld ung en ( Aufl ist ung) /F ehl er E 013 [SK 200 E .. . S K 5 xxE] @ 2\mod_1347454271218_388.docx @ 46751 @ @ 1
E013
13.0 Encoder error
No signal from encoder
• Check 5V sensor if present.
• Check supply voltage of encoder.
13.1 Speed slip error
"Speed slip error"
The slip speed error limit was reached.
• Increase setting in P327.
13.2 Shut-down monitoring
The slip error monitoring has triggered; the motor could not
follow the setpoint.
• Check motor data P201-P209! (Important for the
current controller)
• Check motor circuit.
• In servo mode, check the encoder setting P300 and
check the following
• Increase setting value for torque limit in P112.
• Increase setting value for current limit in P536.
• Check deceleration time P103 and extend if
necessary
13.5 Reserved
Error message for POSICON  see supplementary
instructions
13.6 Reserved
Error message for POSICON  see supplementary
instructions
Pos: 66 2 /Anlei tung en/El ektr onik/FU und Star ter/6 . Meld ung en z um B etr iebs zus ta nd/S tör mel dung en (Auf list ung )/F ehl er E 014 "res er viert " [ SK 200 E ... S K 5 xxE] @ 2\ mod_1347454273854_388.docx @ 46776 @ @ 1
E014
--- Reserved
Error message for POSICON  see supplementary
instructions
Pos: 66 3 /Anlei tu nge n/El ektr oni k/FU un d St art er/6 . M eld ung en z um B etr iebs zus ta nd/S tör mel dung en (Auf list ung )/F ehl er E 015 [SK 180 E . .. S K 5 xxE ] @ 2\ mod_1347454278051_388.docx @ 46801 @ @ 1
E015
--- Reserved
Pos: 66 4 /Anlei tung en/El ektr onik/FU und Star ter/6 . Meld ung en z um B etr iebs zus ta nd/S tör mel dung en (Auf list ung )/F ehl er E 016 [SK 135 E . .. S K 5 xxE, SK xx xE-FD S] @ 2\mod_1347454280625_388.docx @ 46826 @ @ 1
E016
16.0 Motor phase error
A motor phase is not connected.
•
Check P539
• Check motor connection
16.1 Magnetisation current
monitoring
"Magnetisation current
monitoring"
Required exciting current not achieved at moment of switch-
on.
•
Check P539
• Check motor connection
Pos: 66 5 /Anlei tung en/El ektr onik/FU und Star ter/6 . Meld ungen zum Betr iebs zus ta nd/S tör mel dung en (Auf list ung )/F ehl er E 018 "res er viert " [ SK 2xx E/SK 5x xE/S K 2xxE -FDS] @ 2\ mod_1347454282777_388.docx @ 46851 @ @ 1
E018
18.0 Reserved
Error message for "Safe Pulse Block"  see supplementary
instructions
Pos: 66 6 /Anlei tu nge n/El ektr oni k/FU un d St art er/6 . M eld ung en z um B etr iebs zus ta nd/S tör mel dung en (Auf list ung )/F ehl er E 019 [SK 180 E/ SK 2 xxE/SK 5xxE/SK2xxE-FDS] @ 2\mod_1347454285788_388.docx @ 46876 @ @ 1
E019
19.0 Parameter identification
"Parameter identification"
Automatic identification of the connected motor was
unsuccessful
• Check motor connection
• Check preset motor data (P201 … P209)
• PMSM – CFC Closed Loop Operation: Rotor position
of motor incorrect in relation to incremental encoder
Perform determination of rotor position (initial enable
after a "Mains on" only with motor stationary (P330)
19.1 Star / Delta circuit incorrect
"Motor star / delta circuit
incorrect"
