7.7 Electrical data for UL certification
The data given in this section must be taken into account in order to comply with UL certification.
“Suitable for use on a circuit capable of delivering not more than 5000 rms symmetrical Amperes, 120 Volts
maximum (SK 2xxE-xxx-112), 240 Volts maximum (SK 2xxE-xxx-x23) or 500 Volts maximum (SK 2xxE-xxx-
340) and minimum one of the two following alternatives.”
Size 1 – 1~115V mains
Device type: SK 2xxE… -250-112-O -370-112-O -550-112-O -750-112-O
Nominal motor power
(4-pole standard motor)
110V 0.25 kW 0.37 kW 0.55 kW 0.75 kW
120V
1
/
3
hp ½ hp ¾ hp 1 hp
FLA 1 AC
[A] 8.9 A 10.8 A 13.1 A 20.1 A
Rec. mains fuse
J Class Fuse,
600V
10 A 13 A 20 A 25 A
Bussmann B or G LPJ-10SP LPJ-13SP LPJ-20SP LPJ-25SP
Size 1 / 2 – 1~230V mains
Device type: SK 2xxE… -250-123-A -370-123-A -550-123-A -750-123-A -111-123-A
Nominal motor power
(4-pole standard motor)
220V 0.25 kW 0.37 kW 0.55 kW 0.75 kW 1.1 kW
240V
1
/
3
hp ½ hp ¾ hp 1 hp 1½ hp
FLA 1 AC
[A] 3.9 5.8 7.3 10.1 14.6
Rec. mains fuse
J Class Fuse,
600V
4 A 5 A 7 A 9 A 13 A
Bussmann B or G LPJ-4SP LPJ-5SP LPJ-7SP LPJ-9 SP LPJ-13SP
Size 1 – 3~230V mains
Device type: SK 2xxE… -250-323-A -370-323-A -550-323-A -750-323-A -111-323-A
Nominal motor power
(4-pole standard motor)
220V 0.25 kW 0.37 kW 0.55 kW 0.75 kW 1.1 kW
240V
1
/
3
hp ½ hp ¾ hp 1 hp 1½ hp
FLA 3 AC
[A] 1.4 1.9 2.6 3.6 5.1
Rec. mains fuse
J Class Fuse,
600V
2½ A 3½ A 4½ A 6 A 8
Bussmann B or G LPJ-2½SP LPJ-3½SP LPJ-4½SP LPJ-6SP LPJ-8SP
Size 2 / 3 - 400V mains
Device type: SK 2xxE… -151-323-A -221-323-A -301-323-A -401-323-A
Nominal motor power
(4-pole standard motor)
220V 1.5 kW 2.2 kW 3.0 kW 4.0 kW
240V 2 hp 3 hp 4 hp 5 hp
FLA 3 AC
[A] 6.6 9.1 11.7 14.9
Rec. mains fuse
J Class Fuse,
600V
10 A 15 A 17½ A 25 A
Bussmann B or G LPJ-10SP LPJ-15SP LPJ-17½SP LPJ-25SP
