Hardware description
4.7.1 nRF9160 DK board control
The nRF52840 controls analog switches on the nRF9160 DK, enabling routing of some of the nRF9160
GPIO pins to onboard functionality, for example LEDs, or the regular GPIO interfaces.
For details on which GPIOs on the nRF9160 can be routed by these analog switches, see the table below.
Destination
1
Name nRF52 control GPIO nRF9160 GPIO
Default Optional
P0.26 VCOM0_RTS P27_pin6
P0.27 VCOM0_CTS P27_pin7
P0.28 VCOM0_TXD P27_pin8
nRF91_APP1 P1.14
P0.29 VCOM0_RXD P1_pin4
P1.12 P0.01 P14_pin2 VCOM2_RXD
P0.00 P14_pin1 VCOM2_TXD
P0.15 P10_pin2 VCOM2_RTS
nRF91_APP2
P0.14 P10_pin1 VCOM2_CTS
nRF91_LED1 P1.05 P0.02 LED1 P14_pin3
nRF91_LED2 P1.07 P0.03 LED2 P14_pin4
nRF91_LED3 P1.01 P0.04 LED3 P14_pin5
nRF91_LED4 P1.03 P0.05 LED4 P14_pin6
nRF91_SWITCH1 P1.09 P0.08 SWITCH1 P19_pin1
nRF91_SWITCH2 P0.08 P0.09 SWITCH2 P19_pin2
nRF91_BUTTON1 P0.06 P0.06 BUTTON1 P14_pin7
nRF91_BUTTON2 P0.26 P0.07 BUTTON2 P14_pin8
P0.17 P10_pin4 nRF52_P0.17
P0.18 P10_pin5 nRF52_P0.20
nRF91_GPIO P0.13
P0.19 P10_pin6 nRF52_P0.15
P0.21 P4_TRACECLK nRF52_P0.22
P0.22 P4_TRACEDATA0 nRF52_P1.04
NRF91_TRACE P0.24
P0.23 P4_TRACEDATA1 nRF52_P1.02
COEX0 P1_COEX0_PH nRF52_P1.13
COEX1 P1_COEX1_PH nRF52_P1.11
NRF91_COEX P1.10
COEX2 P1_COEX2_PH nRF52_P1.15
Table 4: Board control routing
Name
The name to be used when referring to this signal path and the configuration needed to control it.
1
For the location of connectors, see Figure 6: nRF9160 DK (PCA10090), front view on page 14
4418_1216 v0.9.1
