Nordson 3100V Series - Hose Installation Guidelines

Installation
A1-13
E 2000 Nordson Corporation
All rights reserved
41-3000V
Issued 5/00
A3EN-04-[3V-A-AAXP]-12
5920010
P/N 111 940
X=13 mm (0.50 in.)
R=203 mm (8.00 in.)
P/N 271 486 -- 8 mm (5/16 in.)
P/N 274 174 -- 16 mm (5/8 in.)
X
P/N 274 174 -- 29 mm (1 1/8 in.)
Fig. A 1 -8 Hose Installation Guidelines
