Because Series 3000V units can have up to six hose and gun zones and
one or two internal zones, zone numbers are used to identify specific
zones of each type. When you program TEMPERATURE settings, the
number in the Selector display represents a particular zone number.
Table A 1-14 Heating Zone Numbers
Zone Number
Zone Type
(See Note A)
INTERNAL HOSE GUN
0 Set All
(See Note B)
1 Tank Hose 1 Gun 1
2 Grid
(See Note C)
Hose 2 Gun 2
3 Hose 3 Gun 3
4 Hose 4 Gun 4
5
(See Note D)
Hose 5 Gun 5
6
(See Note D)
Hose 6 Gun 6
NOTE A: Your unit may be able to control the temperature of two, four,
or six hoses and guns, depending upon the unit and features
you have selected.
B: Use Set All to set all zones to the same temperature. Only
zones that are turned on are affected.
C: Some units do not have a grid.
D: Some units can accept only four hoses and four guns.
P
r
og
r
a
m
m
i
n
gT
E
M
P
E
R
A
T
U
R
E
Co
n
t
r
o
l
s
(contd.)
