5. See Figure A 3-19. Size your electrical service line based on the
maximum amperage shown in the AMPS (max.) portion (2) of the
identification plate. The line must also meet local electrical code
requirements.
WARNING: Risk of equipment damage, personal injury or
death. Install a strain relief to protect wires from being
damaged by the edges of the knockout hole.
CAUTION: Circuit boards can be easily damaged. Avoid any
contact with circuit boards when removing a knockout hole plug.
6. If you have not already done so, remove and discard the plug from a
knockout hole on either the back side or the bottom of the unit
(whichever is most convenient for your operation) and install a strain
relief in the hole. Refer to the following table for the appropriate size
strain relief.
NOTE: Your unit may have several knockout holes. You should route
your electrical service wiring through a smaller hole.
Size of Knockout Hole
Size of Strain Relief to Install
23 mm (
15
/
16
in.) PG-16 or
1
/
2
-in. trade size
29.5 mm (
15
/
32
in.) PG-21
35 mm (1
3
/
8
in.) 1-in. trade size
Co
ec
g
ec
ca
Se
v
ce
contd.)
