You can now scroll through all parameters in the setting mode. To change a parameter push the
ENTER button and the value can be changed. The new value needs to be confirmed by pushing the
ENTER button again for 2 seconds otherwise the changed value will not be saved, but instead the
message “Program cancelled” will be displayed. The values can only be changed within the range
shown in the last column. The value between brackets is the factory setting. Following fields can be
displayed:
Level Display Description Setting range
2.1 EXIT MENU SYSTEM Press ENTER to leave the menu system
2.2
DP MIN
P02 xxx daPa
Setting of DeltaP Min value 10 – 190 daPa (40)
2.3
DP MAX
P03 xxx daPa
Setting of DeltaP Max value 30 – 340 daPa (80)
2.4
DP MAX ALARM
P04 xxx daPa
Setting of DeltaP Max Alarm value 20 – 350 daPa (150)
2.5
LOW PRESS ALARM
P05 xxx daPa
Setting of Low pressure alarm value
0 – 200 daPa (0 =
Alarm off)
2.6
OFF LINE CLEAN C
P06 xx CYCLES
Setting of Offline Cleaning Cycles 0 – 15 cycles (0)
2.7
ST TR SW TIME
P07 xxx SEC
Setting of Star/Triangle switch time 1 – 60 s (5)
2.8
PULSE INTERVAL 1
P09 xxx SEC
Setting of Pulse Interval 2 – 30 s (10)
2.9
CLEAN PULSE TIME
P12 xxx MS
Setting of valve Pulse time 40 – 235 ms (100)
2.10
DISPLAY LANG
P15 ENGLISH
Setting the Display Language
See chapter 7.10 for
different options
2.11
INPUT FUNCT I1
P17 0 (actual Mode)
Setting the alarm function of input I1.
See chapter 7.11 for
different options
2.12
INPUT FUNCT I2
P18 0 (actual Mode)
Setting the alarm function of input I2.
See chapter 7.12 for
different options
2.13
OUTPUT FUNCT O1
P19 0 (actual Mode)
Setting of function for output O1
See chapter 7.13 for
different options
2.14
OUTPUT FUNCT O2
P20 0 (actual Mode)
Setting of function for output O2
See chapter 7.14 for
different options
2.15
DP CLEAN MODE
P22_(actual Mode)
Setting of the Delta P Cleaning Mode
See chapter 7.15 for
different options
2.16
NUMBER VALVES
P26 xxx VALVES
Shows the number of valves No setting possible
2.17
T/D DISPLAY
P40 (Actual Mode)
Setting of summer and winter time or
automatic switch between summer and
winter
See chapter 7.17 for
different options
2.18
DATE
P41 DD.MM.20YY
Setting of date (day / month / year)
2.19
TIME
P41 hh:mm
Setting of time
2.19
PROGRAM VERSION
P44 VXX.XX.XX/X
Shows the version of the program No setting possible
