19
2.20
ACTIVE PULSE
P46 VALVE XX YY
Shows the valve that is being pulsed.
XX: Number of module
YY: Number of valve
No setting possible
2.21
TEST CONTROLLER
P48 END
After pressing ENTER all LED’s on the
control panel light up for 10 sec
2.22
TOTAL OPERAT H
M05 XXXXXX HOURS
Shows the total number of operating
hours
No setting possible
2.23
FACTORY SETTINGS
P50
Resetting all values to factory settings
2.24
SETTING MODE PIN
P00 XXXX
Setting a new PIN code by the customer 4-digit code (9999)
7. PARAMETER/MEMORYFIELDSDESCRIPTION
7.1. P00 Setting Pin code
The setting mode access pin code can be changed in the setting mode. The setting mode can only be
entered by first entering the current PIN code. (Factory default PIN code = 9999)
7.2. P02 Delta P Min
DP_MIN__________
PO2_____XXX_daPa
Once the cleaning has started, if the differential pressure drops below the value DP Min for at least 10
seconds, the cleaning stops.
7.3. P03 Delta P Max
DP_MAX__________
PO3_____XXX_daPa
When the fan set is switched on, and the differential pressure increases to above the DP Max value for
at least 10 seconds, the cleaning sequence is started.
7.4. P04 Delta P Max Alarm
DP_MAX_ALARM____
PO4_____XXX_daPa
When the fan set is switched on, and the differential pressure rises above the DP Max Alarm value for
at least 10 seconds, the DP Max Alarm is displayed. The alarm can be switched off after pushing the
ENTER button when the differential pressure drops to a value at least 10% less than Delta P max. You
can switch off the Delta P max alarm function by setting its value to “0”.
7.5. P05 Low Pressure Alarm
LOW_PRESS_ALARM_
PO5_____XXX_daPa
If one minute after the fan set is switched on, the differential pressure is less than the value of the Low
Pressure Alarm for at least 10 seconds, a Low Pressure alarm is displayed. This alarm can be
switched off after pushing the ENTER button when the differential pressure has risen above the Low
pressure alarm. You can switch off the Low pressure alarm function by setting its value to “0”.
