Nordson TCB User Manual

Installation, Operation and Maintenance Manual
30
11. SPECIFICATIONS
Printed Circuit Boards Data
Supply voltage 24 V (AC or DC): -0%/+10%
Back-Up Battery CR 2032. 3 Volts
Bus RS-485 bus link with 9600 Baud bit rate
Inputs Signal Potential free contacts only
Differential Pressure
Transducer
0-500 daPa, Display Range 0-500 daPa. Accuracy - 2,5%
Signal output (Option) 4-20mA output proportional to differential pressure of
0 – 500 daPa
Relay outputs Max. 2 A, 250 VAC or 1 A, 30 VDC
Valve outputs 24 V DC
Single I/O module system - Max. 1,9 A
(2 x 22W Valve per output)
Slave I/O modules - Max. 1.0 A (1 x 22W Valve per output)
Fuse I/O Module T 2,0 A, 250 VAC, 5 x 20 mm
Display – PTC Device.
Dimensions Display PCB. 258 x 175 x 65 mm
I/O Module PCB 220 x 80 mm
12. SPAREPARTS
ITEM Nordson Part No.
TCB,DISPLAY,CONTROLLER,GEN5 A/F 7034116
TCB, I/O MODULE,GEN5 A/F 7034117

Nordson TCB Specifications

General

Brand	Nordson
Model	TCB
Category	Control Unit
Language	English
