Normstahl SPARK - LCU60 E Electronic Board

24
IP2449EN
BIXMR2
L
N
SCI
J11
J13
J5
J3
J1
J4
J8J7J6
J14
J17
J10
J9
RADIO RX
Electric lock Flashing light
24 V / Photocells
ANT WS LP
24V
PX
Wall-Station
Step-by-step Closing safety device Stop +
+
+
-
+
-
1+
-
-
LED internal
light (built-in)
BAT
BBK1500X1
(optional)
Motor
5890
UP
DOWN
ENTER
ESC
L = 175 mm (433 MHz) L = 90 mm (868 MHz)
Power
supply
10.1 LCU60E electronic board
The figure shows the LCU60E electronic board and its connectors for connection to the power
supply, motor and accessories.
