6
IP2449EN
1. Technical data
SPARK600SN
SPARK600SC
SPARK1000SN
SPARK1000SC
Power supply 100 V~ / 240 V~, -10%/ +10%, 50/60 Hz
100-120 V~ / 200-240 V~
(selectable by switch), 50/60 Hz
in case of 120 V power supply, switch
the selector of the power supply unit
Power 100 W 150 W
Motor power supply 24 V
Control panel LCU60E
Power supply for accessories
24 V
/ 0,3 A max 2 s
24 V / 0,15 A continuous
Standby < 0,8 W
Networked Equipment
(unplugged accessories)
Thrust 600 N 1000 N
Opening speed 8-22 cm/s adjustable - 20 cm/s (Default)
Closing speed 8-22 cm/s adjustable - 10 cm/s (Default)
Maximum door area (
*
)
12 m² 17 m²
Maximum door weight 130 kg 200 kg
Service class
INTENSIVE
(tested up to 200,000 cycles)
Intermittence
S2= 60 min (T= 25°C)
S3= 75% (T= 25°C)
Cycle/hour ** 70 (T= 25°C)
Continuous cycles ** 100 (T= 25°C)
Working temperature (T)
-20°C +55°C
Degree of protection IP20
Noise level L
PA
<55 dB (A) (operator only)
Remote control functions /
programmable keys
100= (
→ → / )
200= (
→ → / )
Radio frequency
433.92 MHz ( → → )
868.35 MHz default (
→ → )
Maximum remote control range 50 m
Courtesy light Built in: LED 1750 lms Built in: LED 3500 lms
**indicative cycles considering a 2350 mm high door and factory settings (default opening speed of 20 cm/s
and closing speed of 10 cm/s). Speeds are configurable up to 22 cm/s. With higher speeds, the number of
cycles increases. A cycle is considered an opening maneuver followed by a closing maneuver
TS150X2 TS200X2
Track system length 3300 mm 4400 mm
Maximum carriage stroke 2875 mm 3975 mm
Maximum door height 2350 mm 3450 mm
*
the maximum door area was calculated based on a weight of 10.9 kg/m²
