Nortel DMS-10 - NT6 M60 BA Quad SIO (Slot 6), BMC Set to INTERNAL Timing and Polling Modem Set to EXTERNAL Timing; NT6 M60 BA Quad SIO (Slot 6), BMC Set to EXTERNAL Timing and Polling Modem Set to INTERNAL Timing

PCA Switch and Strap Settings 49
BMC II BISYNC Quick Reference Guide
Note 2: ADDRESS SELECTION SW1 = A is required for SIO inserted
into slot 6.
Note 3: For baud selection, use Table 9.
Table 7
NT6M60BA Quad SIO (Slot 6), BMC set to INTERNAL timing
and Polling Modem set to EXTERNAL timing
Port Description Jumper Pin
Baud
Selection
J1 = SDI Port
(DMS-10) ASYNC
J2
J3
J10
1-2
1-2
IN
Baud 1
(SW2)
J2 = DOWNLOAD
Link ASYNC
J4
J5
J11
1-2
2-3
IN
Baud 2
(SW3)
J3 = POLLING Link
SYNC/BISYNC
J6
J7
J12
1-2
2-3
IN
Baud 3
(SW4)
J4 = Local TTY
ASYNC
J8
J9
J13
1-2
1-2
IN
Baud 4
(SW5)
Table 8
NT6M60BA Quad SIO (Slot 6), BMC set to EXTERNAL timing
and Polling modem set to INTERNAL timing
Port Description Jumper Pin
Baud
Selection
J1 = SDI Port
(DMS-10) ASYNC
J2
J3
J10
1-2
1-2
OUT
Baud 1
(SW2)
J2 = DOWNLOAD
Link ASYNC
J4
J5
J11
2-3
2-3
OUT
Baud 2
(SW3)
J3 = POLLING Link
SYNC/BISYNC
J6
J7
J12
2-3
2-3
OUT
Baud 3
(SW4)
J4 = Local TTY
ASYNC
J8
J9
J13
1-2
1-2
IN
Baud 4
(SW5)
