Nortel DMS-10 - Baud Rate Reference

50 PCA Switch and Strap Settings
297-6201-501 97Q3 Standard 02.01 July 1997
Note 4: The Asynchronous rate is used for the SDI port (J1), Local
TTY port and the Software Download port (J2). The Synchronous rate
is used for the Polling port (J3).
Table 9
Baud Rate Reference
Rotary Switch
Position
Asynchronous
Rate
Synchronous
Rate
0 50 800
1 75 1200
2 110 1760
3 134.5 2152
4 150 2400
5 300 4800
6 600 9600
7 1200 N/A
8 1800 N/A
9 2000 N/A
A 2400 N/A
B 3600 N/A
C 4800 N/A
D 7200 N/A
E 9600 N/A
F N/A N/A
