Nortel DMS-10 - Nt6 M90 Xx 1600 Bpi DCO TEC PCA

PCA Switch and Strap Settings 55
BMC II BISYNC Quick Reference Guide
Table 16
NT6M90xx 1600 bpi DCO TEC PCA
SLOT 12
Switch # Position
S1 1 OFF
2 ON
3 OFF
4 ON
5 ON
6 OFF
7 ON
8 OFF
9 OFF
10 OFF
S2 1 OFF
2 OFF
3 ON
4 OFF
5 ON
6 OFF
7 OFF
8 OFF
9 ON
10 OFF
SLOT 13
Switch # Position
S1 1 OFF
2 OFF
3 OFF
4 ON
5 ON
6 OFF
7 ON
8 OFF
9 OFF
10 OFF
S2 1 OFF
2 OFF
3 ON
4 OFF
5 ON
6 OFF
7 OFF
8 OFF
9 ON
10 OFF
