Nortel DMS-10 - Nt6 M70 Xx DMS-100 DSI PCA

52 PCA Switch and Strap Settings
297-6201-501 97Q3 Standard 02.01 July 1997
Table 13
NT6M70xx DMS-100 DSI PCA
SLOT 12
Switch # Position
SW1 1 OFF
2 ON
3 ON
4 OFF
5 OFF
6 OFF
7 ON
8 ON
9 OFF
10 OFF
SW2 1 ON
2 OFF
3 OFF
4 ON
SLOT 13
Switch # Position
SW1 1 OFF
2 OFF
3 ON
4 OFF
5 OFF
6 OFF
7 ON
8 ON
9 OFF
10 OFF
SW2 1 ON
2 OFF
3 OFF
4 ON
