1200 Series Display, Rev. A2 Front Panel — Page 7
Red Mode turns data images to a reddish hue, both in Hi and Lo
mode. This is particularly useful for running at night when your
navigator is displayed on your 1201/1202. Press again to turn off.
The HI/LO Button
This feature is available only when the optional vBox is
connected. It selects a day (Hi) or night (Lo) range of the
displayed data or video image. Lower intensity images are more
useful at night.
The MENU Button
This button configures picture quality settings in your
display. Since changing these settings can degrade your
picture quality, Northstar recommends that you don’t adjust the
factory settings.
1201
Northstar ships your 1201 pre-adjusted for the
maximum video quality. Only in rare cases will
further adjustment be necessary. If you are experi-
encing problems with image quality, follow the guidelines in
the section on troubleshooting beginning on page 38.
1202
1202 users will use primarily to turn the
Picture-In-Picture (PIP) feature on and off as
described on page 4.
is also used for adjusting image quality. Only in rare
cases will adjustment be necessary. If you are experiencing
problems with image quality, follow the guidelines in the
section on troubleshooting beginning on page 38.
HI/LO
MENU
1201
1202
MENU
MENU
