Page 4 — What’s in this Manual 1200 Series Display, Rev. A2
what’s connected to the BNC Video connector. Press both
buttons at once to view Picture-In-Picture (see below).
With the optional vBox, you can have up to four inputs: your
original Data and Video source, plus an Auxiliary Data and
Video source. Each time you press the display will
switch between the two Data sources you have connected.
The same is true for .
Using Picture-In-Picture on the 1202
The 1202 includes a feature called Picture-In-Picture (PIP)
which allows display of a full screen of data with a smaller
video image on top of it. This is useful if you want a view of
your engine room in the corner of your navigator display. PIP
is available only on the 1202. More complete information
about PIP settings can be found on page 14.
Turning the Display Off
To turn the display off, simply press and hold for a few
seconds until the display shuts off.
DATA
VIDEO
PWR
