1200 Series Display, Rev. A2 Optional vBox — Page 33
having at least one connection to each of the primary and
auxiliary connectors.
The advantage of connecting the VIDEO OUT to AUX VIDEO
is that you can then view your single video source as a PIP
on top of either the DATA or AUX DATA image. Refer to the
picture on the left above.
The advantage of connecting the DATA OUT to AUX DATA is
that you can then view either your VIDEO or AUX VIDEO
source as a PIP on top of the single data image. Refer to the
picture on the right above.
PIP with the vBox
This feature allows display of a video image on top
of a VGA data image. For example, you may want to
keep an eye on your engine room camera while
viewing a chart on your navigator.
The 1202 treats the primary inputs (DATA and VIDEO) as a
pair and the auxiliary inputs (AUX DATA and AUX VIDEO) as
a pair. PIP can only display the two primary or two auxiliary
NOTE: Do not connect DATA OUT to DATA.
Do not connect VIDEO OUT to VIDEO.
This will damage the vBox.
!
1202
