Appendix B — Specifications
Power
Power Source: 10 – 36 VDC
Power Consumption: 50 – 60 W
Fuse: Standard 7 Amp fuses (supplied)
Environmental
Display meets IEC 529 IPX-6
Optional vBox Requires dry installation
Temperature 0º C – 55º C maximum
Humidity 95 percent relative humidity, non-
condensing
Temperature – Operating –10º C to +55º C
Temperature – Storage –20º C to +80º C
Signal Resolution / Format
1201 Input SVGA (800 x 600)
VGA (640 x 480)
1202 Input UXGA (1600 x 1200)
SXGA (1280 x 1024)
XGA (1024 x 768)
SVGA (800 x 600)
VGA (640 x 480)
Video (1201 and 1202) NTSC/PAL
Display Resolution SVGA (800 x 600)
(1201 and 1202)
Optional vBox
Inputs Two NTSC/PAL
Two Data/VGA
Control/Data/Power
Outputs NTSC/PAL Redrive
Data/VGA Redrive
IR Repeater
