Page 16 — Using the Setup Menu 1200 Series Display, Rev. A2
OSD Settings
OSD Setting allows you to place the Setup Menu wherever
you’d like it on the screen.
OSD Background allows the Setup Menu to be either
Translucent or Opaque. Many users find it easier to read in
the Opaque setting.
OSD Rotate should always be set to Normal.
Freeze. Northstar recommends not freezing the image.
Zoom enables the zoom function on the image displayed. If
the image has been zoomed, then you can use the Hori-
zontal Pan and Vertical Pan to display the image.
Direct Access #1 should always be set to Brightness.
Direct Access #2 should always be set to Contrast.
Display Orientation should always be set to Normal.
Calibrate RGB Gain causes the display to re-calibrate its
colors automatically when displaying an image from the data
input. When displaying a new VGA data source for the first
time, this calibration helps set colors properly.
Load Factory Defaults restores the factory default settings.
This is particularly useful if the display has been adjusted to
an undesirable state.
Exit Menu
Use this icon to exit the Setup Menu. Once at the
Exit icon, press to exit the Setup Menu.
As a shortcut, you can also hold down until
the Setup Menu disappears.
EXIT
VIDEO
MENU
To Next Page
