Notifier AFP-2800 User Manual

Panel Operation
36 AFP-2800/2802 Manual – P/N 11249 11-Mar-08
6.3.3.7.2.1.1 Service Menu – List – List – Analog – Modules – Status – Test
This screen will perform functional tests on selected Analog addressable points. As modules can be both inputs
and outputs, there are two different modes of operation.
If module is an Input Module
L1M1 (Z001) > BREAK GLASS ON PANEL
Poll Mode > FlashScan Mode
Programmed As > FMM-101-MMX-101 MINI MON
Actual Device > FMM-101 MINI MON
Device State > NORMAL
Device Status > NORMAL
LED Status > Polling
USE BUTTONS TO SELECT TEST .
ANALOG MENU – TESTING
A = 0
F = 0
I = 0
N = 0
20 JULY 2002 14:44:37
OFFON
ALARM STATUSFAULT
DAY MODE
Actions:
 Press the ON button to turn module LED’s ON
green (red if CLIP). (This test is useful for locating
detector/detectors at same address)
 Press the OFF button to return module LED’s to
the Automatic Polling Mode
 Press the ALARM button to perform an ALARM
TEST on the module.
 Press the FAULT button to perform an FAULT
TEST on the module.
 Press the STATUS button to return to the read
status screen.
If the module is an Output Module.
L1M10 > EWIS OUPUT #1
Poll Mode > FlashScan Mode
Programmed As > FRM-1/CMX-2 Relay O/P
Actual Device > FMM-1 Relay
Device State > NORMAL
Device Status > NORMAL
LED Status > Polling Green
USE BUTTONS TO SELECT TEST .
ANALOG MENU – TESTING
A = 0
F = 0
I = 0
N = 0
20 JULY 2002 14:44:37
OFFON
STATUS
DAY MODE
Actions:
 Press ON to activate the output module.
 Press OFF to de-activate the output module.
 Press STATUS to return to the read status
screen.
Note: Script processing is paused during an output module test. Scripts will automatically resume processing once
a test is complete.
