Panel Operation
AFP-2800/2802 Manual – P/N 11249 11-Mar-08 35
6.3.3.7.2.1 Service Menu – List – List – Analog – Modules – Status
This screen will show a reading of the selected Analog addressable module updated every 3 seconds, 255 times.
The modules current configuration is displayed together with “live readings” as shown below.
L1M1 (Z000) > BREAK GLASS ON PANEL
Poll Mode > Flashscan Mode
Programmed As > FMM-101-MMX-101 MINI MON
Actual Device > FMM-101 MINI MON
Device State > NORMAL
Device Status > NORMAL
LED Status > Polling
Device Scanned 255 Times .
ANALOG MENU – STATUS
A = 0
F = 0
I = 0
N = 0
20 JULY 2002 14:44:37
DAY MODE
PREV
TEST MenuNEXT RESET
Actions:
 Press the PREV buttons to move to the previous
installed point.
 Press the NEXT buttons to move to the next
installed point.
 Press the TEST button to enter test menu for the
detector.
 Press the RESET button to re-initialise the
detector.
 Press MENU to return to the Analog Menu
screen.
Explanations of terms:
Variable Range Description
Poll Mode
FlashScan or CLIP Shows the current polling protocol being used. FlashScan =
10 modules at a time, CLIP = 1 module at a time. Polling
mode is auto sensed at start-up
Programmed As 9 Types Module type programmed into panel
Actual Device 5 Types Module type physically seen on loop
Device State Normal/Active/Alarm Shows alarm or activated condition of point
Device Status 23 fault types Detailed description of fault condition. I.e. “No Response”
LED Status 4 Types Polling, On, Off, Polling ID
