Panel Operation
42 AFP-2800/2802 Manual P/N 11249 11-Mar-08
6.3.3.11 SERVICE MENU LIST LIST DIN
This screen will list all the digital inputs in the system. Digital inputs consist of non-AZF inputs such as fan control
module status inputs and annunciator panel input buttons/switches.
The display shows the point number (Ring.Module.I/O format) and the point description. In addition, the current
state of the point is displayed.
Unnamed points use the associated field module type as their description.
01.010.I1 SPF 1 RUNNING x
01.010.I2 SPF 1 FAULT
01.010.I3 (FANC)
01.101.I1 BUTTON 1 ON 16AT
01.101.I2 BUTTON 2 ON 16AT
01.101.I3 BUTTON 3 ON 16AT
01.101.I4 BUTTON 4 ON 16AT
01.101.I5 BUTTON 5 ON 16AT
01.101.I6 BUTTON 6 ON 16AT
01.101.I7 BUTTON 7 ON 16AT
01.101.I8 BUTTON 8 ON 16AT
01.101.I9 (ACM16AT)
01.101.I10 (ACM16AT)
01.101.I11 (ACM16AT)
01.101.I12 (ACM16AT)
01.101.I13 (ACM16AT)
01.101.I14 (ACM16AT)
01.101.I15 (ACM16AT)
01.101.I16 (ACM16AT)
DIGITAL INPUT LIST
20 JULY 2002 14:44:37
CHANGEDOWNUP
USE UP/DOWN BUTTONS TO SELECT AN I/P:
A = 0
F = 0
I = 0
N = 1
BACK
DAY MODE
Actions:
Use the UP and DOWN buttons to scroll through
Input points.
Pressing the CHANGE button will take you to the
Modify Point Screen (refer to page 58)
Pressing the BACK button will return you to the list
menu screen.
In the above example, the following abbreviations of STATUS apply.
Status
Abbreviation
Meaning
I Isolated
F Fault
X Activated
Note: You can also use the arrow keys, the Page Up and Page Dn keys on an external keyboard for scrolling
functions.
