6.3.3.15 SERVICE MENU – LIST – SHADOW
This will display the shadow event history list in chronological order. Events are time stamped with date and time
and are shown in point and status format.
The AFP-2800/2802 system stores over 4000 shadow history events. When the shadow history buffer is full, the
system will remove the oldest entries whenever a new entry is received thus leaving the 4000 most recent entries
in the list. This is an automatic process.
The shadow history cannot be erased.
As you scroll up and down the list, the currently highlighted item’s description is shown at the bottom of the
screen.
1: 23/10/98 10:45:56 1.1.Z1 ALARM
2: 23/10/98 10:50:02 1.1.Z1 ACKD ALARM
3: 23/10/98 10:55:34 1.1.Z1 RESET
4: 03/02/99 10:46:13 1.3.Z8 FAULT
5: 03/02/99 10:50:56 1.3.Z8 FAULT SELF CLEARED
6: 03/02/99 10:50:58 1.3.Z2 ISOLATED
7: 03/02/99 10:52:00 L1D1 ALARM
6: 03/02/99 10:50:58 L1D1 ACKD ALARM
IFS DAP700 MENUIFS DAP700 MENUIFS DAP700 MENUIFS DAP700 MENUIFS DAP700 MENU
SHADOW HISTORY LIST
28 JAN 1999 14:44:3728 JAN 1999 14:44:3728 JAN 1999 14:44:3728 JAN 1999 14:44:3728 JAN 1999 14:44:37
20 JULY 2002 14:44:37
DOWNUP
USE BUTTONS/NUMBERS TO SELECT A FUNCTIONUSE BUTTONS/NUMBERS TO SELECT A FUNCTIONUSE BUTTONS/NUMBERS TO SELECT A FUNCTIONUSE BUTTONS/NUMBERS TO SELECT A FUNCTIONUSE BUTTONS/NUMBERS TO SELECT A FUNCTION
ZONE 1, SMOKE, LEVEL 6 APARTMENT 10
A = 0
F = 0
I = 0
N = 0
DAY MODE
BACKPG DWNPG UP
Actions:
 Use the UP , DOWN , PG UP and PG DWN
buttons to scroll through the Shadow History List.
 Pressing the PG UP button when you are on the
first page of the shadow history will wrap the list
around to the last page in the history.
Note: Shadow history is not available on the IFS703 CPU boards. This is due to the size of flash storage on the
older CPU boards. V3 and above firmware is required for this feature.
You can also use the arrow keys, the Page Up and Page Dn keys on an external keyboard for scrolling
functions.
