Notifier AFP-2800 User Manual

Panel Operation
AFP-2800/2802 Manual – P/N 11249 11-Mar-08 45
6.3.3.14 SERVICE MENU – LIST – HISTORY
This will display an abbreviated event history list in chronological order. Events are time stamped with date and
time and are shown in point and status format.
The AFP-2800/2802 system stores 4000 events. The history list will then “over-expand” to 8,000 events and once
it reaches this level, will purge the oldest 4000 entries leaving the 4000 most recent entries in the list. This is an
automatic process.
The history can be totally erased from the diagnostics menu, if necessary (refer page 81).
As you scroll up and down the list, the currently highlighted item’s description is shown at the bottom of the
screen.
1: 23/10/98 10:45:56 1.1.Z1 ALARM
2: 23/10/98 10:50:02 1.1.Z1 ACKD ALARM
3: 23/10/98 10:55:34 1.1.Z1 RESET
4: 03/02/99 10:46:13 1.3.Z8 FAULT
5: 03/02/99 10:50:56 1.3.Z8 FAULT SELF CLEARED
6: 03/02/99 10:50:58 1.3.Z2 ISOLATED
7: 03/02/99 10:52:00 L1D1 ALARM
6: 03/02/99 10:50:58 L1D1 ACKD ALARM
IFS DAP700 MENUIFS DAP700 MENUIFS DAP700 MENUIFS DAP700 MENUIFS DAP700 MENU
HISTORY LIST
28 JAN 1999 14:44:3728 JAN 1999 14:44:3728 JAN 1999 14:44:3728 JAN 1999 14:44:3728 JAN 1999 14:44:37
20 JULY 2002 14:44:37
PG UP
USE BUTTONS/NUMBERS TO SELECT A FUNCTIONUSE BUTTONS/NUMBERS TO SELECT A FUNCTIONUSE BUTTONS/NUMBERS TO SELECT A FUNCTIONUSE BUTTONS/NUMBERS TO SELECT A FUNCTIONUSE BUTTONS/NUMBERS TO SELECT A FUNCTION
ZONE 1, SMOKE, LEVEL 6 APARTMENT 10
A = 0
F = 0
I = 0
N = 0
DAY MODE
BACKPG DWN
DOWNUP
Actions:
 Use the UP , DOWN , PG UP and PG DWN
buttons to scroll through the History List.
 Pressing the PG UP button when you are on the
first page of the history will wrap the list around to
the last page in the history.
Note: You can also use the arrow keys, the Page Up and Page Dn keys on an external keyboard for scrolling
functions.
