6.3.4.5 SERVICE MENU – ISOLATE – VIRTUAL POINT LIST
This screen allows the operator to isolate or de-isolate a virtual point.
VP1 UNNAMED POINT
VP2 UNNAMED POINT
VP3 UNNAMED POINT
VP4 UNNAMED POINT
VP5 UNNAMED POINT
VP6 UNNAMED POINT
VP7 UNNAMED POINT
VP8 UNNAMED POINT
VP9 UNNAMED POINT
VP10 UNNAMED POINT
VP11 UNNAMED POINT
VP12 UNNAMED POINT
VP13 UNNAMED POINT
VP14 UNNAMED POINT
VP15 UNNAMED POINT
VP16 UNNAMED POINT
VP17 UNNAMED POINT
ISOLATE / DE-ISOLATE A POINT
20 JULY 2002 14:44:37
ISOLDOWNUP
SELECT A POINT TO ISOLATE:
A = 0
F = 0
I = 0
N = 0
DEISOLACKN
DAY MODE
Actions:
Use the UP and DOWN buttons to select the
appropriate point and then press the ISOL button
to isolate or the DEISOL button to de-isolate the
point. If the point is isolated, an “I” will appear on
the right hand side of the screen next to the point.
