AFP-2800/2802 Manual – P/N 11249 11-Mar-08 49
6.3.4.3 SERVICE MENU – ISOLATE – DOUT LIST
This screen allows the operator to isolate or de-isolate an output point.
00.004.01 BELL OUTPUT
00.004.O2 WARNING SYSTEM
00.004.O3 A/C TRIP
00.004.O4 (LOCAL RELAY)
00.004.O5 GENERAL ALARM OUTPUT
00.004.O6 COMMON FAULT OUTPUT
00.004.O7 COMMON ISOLATE OUTPUT I
00.004.08 (LOCAL RELAY)
01.001.O1 LEVEL 1 OUTPUT
01.001.O2 LEVEL 2 OUTPUT
01.001.O3 LEVEL 3 OUTPUT
01.001.O4 (AZM8)
01.002.O1 (AZM8)
01.002.O2 (AZM8)
01.002.O3 (AZM8)
01.002.O4 (AZM8)
ISOLATE / DE-ISOLATE A POINT
20 JULY 2002 14:44:37
ISOLACKNDOWNUP
SELECT A POINT TO ISOLATE:
A = 0
F = 0
I = 1
N = 0
DEISOL
DAY MODE
Actions:
 Use the UP and DOWN buttons to select the
appropriate point and then press the ISOL button
to isolate or the DEISOL button to de-isolate the
point. If the point is isolated, an “I” will appear on
the right hand side of the screen next to the point.
6.3.4.4 SERVICE MENU – ISOLATE – DIN LIST
This screen allows the operator to isolate or de-isolate an input point.
01.010.I1 SPF 1 RUNNING x
01.010.I2 SPF 1 FAULT
01.010.I3 (FANC)
01.101.I1 BUTTON 1 ON 16AT I
01.101.I2 BUTTON 2 ON 16AT
01.101.I3 BUTTON 3 ON 16AT
01.101.I4 BUTTON 4 ON 16AT
01.101.I5 BUTTON 5 ON 16AT
01.101.I6 BUTTON 6 ON 16AT
01.101.I7 BUTTON 7 ON 16AT
01.101.I8 BUTTON 8 ON 16AT
01.101.I9 (ACM16AT)
01.101.I10 (ACM16AT)
01.101.I11 (ACM16AT)
01.101.I12 (ACM16AT)
01.101.I13 (ACM16AT)
01.101.I14 (ACM16AT)
01.101.I15 (ACM16AT)
01.101.I16 (ACM16AT)
ISOLATE / DE-ISOLATE A POINT
20 JULY 2002 14:44:37
ISOLDOWNUP
SELECT A POINT TO ISOLATE:
A = 0
F = 0
I = 1
N = 1
DEISOLACKN
DAY MODE
Actions:
 Use the UP and DOWN buttons to select the
appropriate point and then press the ISOL button
to isolate or the DEISOL button to de-isolate the
point. If the point is isolated, an “I” will appear on
the right hand side of the screen next to the point.
