6.3.5.1.6 SERVICE MENU – CONFIG – CHANGE – ANALOG POINT
Once you have selected an Analog addressable point from the list or entered directly, you will be on modify
Analog point screen. This screen will be different depending on what type of Analog addressable point is selected.
I.e. Detector, Input Module or Output Module.
Detectors:
SELECTED POINT : L1D1
L1D1 > APARTMENT 1 BATHROOM
DEVICE TYPE > PHOTO
ZONE NO. > 2
ZONE TYPE > SMOKE
ALARMED? (Y/N) > Y
LATCHED? (Y/N) > Y
AVF? (Y/N) > N
SENSITIVITY 1-9: (1 is most sensitive)
Day Alarm 5 Day Pre-Alarm 4
Night Alarm 1 Night Pre-Alarm 1
ANALOG MENU – PROG
A = 0
F = 0
I = 0
N = 0
20 JULY 2002 14:44:37
BACKSP
ENTER
DAY MODE
Actions:
 Press the BACKSP button to delete an incorrect
character.
 Press the ENTER button to step through options.
 Press the YES or NO buttons when highlighted
to answer Y/N options.
 Use external QWERTY keyboard to edit
descriptors and zone type.
 The numerical keypad can be used for numerical
entries.
 When entering device type a numerical pick list
will appear at the bottom of the screen.
 Refer to appendix for more information on options
and sensitivity settings.
 You will be prompted Yes/No to save changes
when finished.
