Input modules:
SELECTED POINT : L1M1
L1M1 > BREAK GLASS MAIN FOYER
DEVICE TYPE > FMM-101/MMX-1010 MINI MON
ZONE NO. > 2
ZONE TYPE > MCP
ALARMED? (Y/N) > Y
LATCHED? (Y/N) > Y
TIMED? (Y/N) > N
AVF? (Y/N) > N
FLASHSCAN MENU – PROG
A = 0
F = 0
I = 0
N = 0
20 JULY 2002 14:44:37
BACKSP
ENTER
DAY MODE
Actions:
 Press the BACKSP button to delete an incorrect
character.
 Press the ENTER button to step through options.
 Press the YES or NO buttons when highlighted
to answer Y/N options.
 Use external QWERTY keyboard to edit
descriptors and zone type.
 The numerical keypad can be used for numerical
entries.
 When entering device type a numerical pick list
will appear at the bottom of the screen.
 Refer to appendix for more information on options
and sensitivity settings.
 You will be prompted Yes/No to save changes
when finished.
Output modules:
SELECTED POINT : L1M10
L1M10 > EWIS OUTPUT #1
DEVICE TYPE > FRM-1/CMX-2 RELAY O/P
FLASHSCAN MENU – PROG
A = 0
F = 0
I = 0
N = 0
20 JULY 2002 14:44:37
BACKSP
ENTER
DAY MODE
Actions:
 Press the BACKSP button to delete an incorrect
character.
 Press the ENTER button to step through options.
 Press the YES or NO buttons when highlighted
to answer Y/N options.
 Use external QWERTY keyboard to edit
descriptors and zone type.
 The numerical keypad can be used for numerical
entries.
 When entering device type a numerical pick list
will appear at the bottom of the screen.
 Refer to appendix for more information on options
and sensitivity settings.
 You will be prompted Yes/No to save changes
when finished.
Once the output module name and type has been saved, you will then be transferred to the script entry screen
and be prompted to enter a script for the output. Please refer to page 90 for more information on entering scripts.
