Notifier AFP-2800 User Manual

Panel Operation
AFP-2800/2802 Manual – P/N 11249 11-Mar-08 65
6.3.6.5 SERVICE MENU – ANALOG – LOOP
This menu item allows several diagnostic functions to be performed on the loops themselves. Firstly you will be
prompted to enter a loop number. Then the screen will appear as follows:
LCM Version -> 2.11
Loop wiring style -> Open
Device led blink -> ON
Detector Poll Style -> FLASHSCAN
Module Poll Style -> FLASHSCAN
ANALOG MENU - LOOP
20 JULY 2002 14:44:37
OFF
NEXT MENU
LOOP 1 SELECTED:
A = 0
F = 0
I = 0
N = 0
AUTOPRG TOGGLE
DAY MODE
Soft button functions:
ON/OFF -> Turn device LED blink ON/OFF
AUTOPROG -> Look for new devices on loop
TOGGLE -> Change the poll mode on loop
Actions:
 Use the NEXT buttons to move to the next loop.
 Pressing the OFF button will turn device blinking
off on the selected loop. If device blinking is already
off, the button will toggle to ON .
 Press the AUOTPRG button to Auto Program the
selected loop. This will add any new detectors and
modules placed on the loop.
 Pressing the TOGGLE button will change the
loops polling mode. If the loop is in clip mode, the
button will toggle it to FlashScan mode. If the loop is
in FlashScan mode, the button will toggle it to CLIP
mode. The toggle button is only available on the
AFP-2800. AFP-2802 can only operate in CLIP
mode
 Pressing the MENU button will return you to the
service menu.
Note: Applicable to V4.xx and below firmware
If the panel is powered down all loops will initialise with led blinking on. Where required, led blinking needs to
be turned off manually after a power up; the panel will not save the state of led blink after a cold reboot.
6.3.6.6 SERVICE MENU – ANALOG – ANALOG
This menu item allows you to set the Loop styles to either Open or Closed loops. The screen will appear as
follows:
LOOP 1 is Open Loop
LOOP 2 is Closed Loop
LOOP 3 is Closed Loop
LOOP 4 is Closed Loop
LOOP 5 is Closed Loop
LOOP 6 is Closed Loop
LOOP 7 is Closed Loop
LOOP 8 is Closed Loop
LOOP 9 is Closed Loop
LOOP 10 is Closed Loop
ANALOG MENU - LOOPS
20 JULY 2002 14:44:37
DOWN
UP BACK
A = 0
F = 0
I = 0
N = 0
TOGGLE
DAY MODE
SET LOOP STYLE FOR INSTALLED LCM/LEM
Actions:
 Use the UP / DOWN buttons to move to the next
loop.
 Pressing the TOGGLE button will change the loop
style for the selected loop between Open and
Closed.
 Pressing the BACK button will return you to the
previous menu.
