6.3.6.7 SERVICE MENU – ANALOG – FAULT
This menu displays the Analog Fault Codes for reference. A list of the fault codes and their description can be
found on page 107.The screen will appear as follows:
(F01) ...... NO RESPONSE
(F02) ...... MISMATCHED DEVICE TYPE
(F03) ...... 2 DEVICES SAME ADDRESS
(F04) ...... INCORRECT RESPONSE
(F05) ...... OPEN CIRCUIT
(F06) ...... SHORT CIRCUIT
(F07) ...... LOW THRESHOLD
(F08) ...... MAINTENANCE ALERT
(F09) ...... MAINTENANCE URGENT
(F11) ...... DETECTOR FAILED TEST
(F14) ...... GROUND FAULT
(F18) ...... GENERAL FAULT
(F21) ...... MODULE EXTERN PWR LOSS
ANALOG MENU
20 JULY 2002 14:44:37
BACK
A = 0
F = 0
I = 0
N = 0
DAY MODE
ANALOG FAULT CODE DEFINITIONS
Actions:
Pressing the BACK button will return you to the
previous menu.
