Notifier AFP-2800 User Manual

Panel Operation
76 AFP-2800/2802 Manual – P/N 11249 11-Mar-08
6.3.7.6 SERVICE MENU – GLOBAL – PRINT
This page displays system global printer port parameters that can be toggled. The default states are shown below
on the left, while the toggled states are shown on the right.
Default Condition Toggled Condition
EVENT PRINTING IS OFF
ALARM ONLY EVENT PRINTING IS OFF
PRINT FORMAT IS SET TO DEFAULT
SYSTEM CONFIGURATION
TOGGLEDOWNUP MENU
SELECT A FUNCTION:
20 JULY 2002 14:44:37
A = 0
F = 0
I = 0
N = 1
DAY MODE
EVENT PRINTING IS ON
ALARM ONLY EVENT PRINTING IS ON
PRINT FORMAT IS SET TO NFS-3030
SYSTEM CONFIGURATION
TOGGLEDOWNUP MENU
SELECT A FUNCTION:
20 JULY 2002 14:44:37
A = 0
F = 0
I = 0
N = 1
DAY MODE
Actions:
 Use the UP and DOWN buttons to scroll through options and then use the TOGGLE button to select the
toggle the highlighted option. Changes are instant.
Explanation of Global Configuration Options:
Item Description
Event Printing
Determines if the panel should print events to the printer port.
Alarm Only Printing
This setting determines if the panel should only print alarm events or all events.
Printing Format
Determines the panel printer port output format. Default setting should be used
unless instructed by Notifier technicians. The non default format is the same as
the Notifier NFS-3030 fire panel format and should only be used in conjunction
with the Fieldserver MODBUS gateway. The NFS-3030 format does not print all
events and should not be used as the standard printing format.
