Notifier AFP-3030 Programming Manual

108 AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015
Intelligent Sensing Applications Detector Sensitivity Settings
Ion (% per metre)
SMOKE (ION)
(See notes
*
,
‡
)
AL:1=1.63% per metre
AL:2=2.44%
AL:3=3.24%
AL:4=4.04%
AL:5=4.83%
AL:6=5.63%
~
AL:7=6.41%
AL:8=7.19%
AL:9=7.97%
PA:1=Auto
PA:2=1.31%
PA:3=1.63%
PA:4=2.44%
PA:5=3.24%
PA:6=4.04%
~
PA:7=4.83%
PA:8=5.63%
PA:9=6.41%
FlashScan Laser
†
(See Note
‡
)
AL:1=0.07% per metre
AL:2=0.10%
AL:3=0.16%
AL:4=0.33%
AL:5=0.65%
AL:6=1.63%
~
AL:7=3.24%
AL:8=4.83%
AL:9=6.41%
PA:1=Auto
PA:2=0.07%
PA:3=0.16%
PA:4=0.33%
PA:5=0.65%
PA:6=1.63%
~
PA:7=2.28%
PA:8=3.24%
PA:9=4.83%
Acclimate
Multi-Sensor AL:1=1.63% per metre
AL:2=3.24%
AL:3=3.24 to 6.41%
AL:4=6.41%
AL:5=6.41 to 9.51%
~
AL:6=9.51%
AL:7=9.51 to 12.5%
AL:8=12.53%
AL:9=thermal 57
o
C
Alarm (CLIP)
AL:1=3.24%
AL:2=3.24%
AL:3=3.24 to 6.41%
AL:4=6.41%
AL:5=6.41 to 12.5%
~
AL:6=6.41 to 12.5%
AL:7=6.41 to 12.5%
AL:8=12.5%
AL:9=12.5%
PA:1=1.63%
PA:2=3.24%
PA:3=3.24%
PA:4=3.24 to 6.41%
PA:5=3.24 to 6.41%
~
PA:6=6.41%
PA:7=6.41%
PA:8=6.41 to 9.51%
PA:9=6.41 to 9.51%
Heat (Adjustable Threshold) AL:1=43
°
C
AL:2=57
°
C
AL:3=63
°
C
~
AL:4=68
°
C
AL:5=74
°
C
AL:6=88
°
C
AL:7=88
°
C
AL:8=88
°
C
AL:9=88
°
C
PA:1=40
°
C
PA:2=43
°
C
PA:3=57
°
C
~
PA:4=65
°
C
PA:5=70
°
C
PA:6=75
°
C
PA:7=75
°
C
PA:8=75
°
C
PA:9=75
°
C
Beam
(See Note
**
)
AL:1=25% total obscuration
AL:2=30%
AL:3=40%
AL:4=50%
AL:5=30 - 50%
AL:6=40 - 50%
PA:1=50%
PA:2=55%
PA:3=60%
PA:4=65%
PA:5=70%
PA:6=75%
PA:7=80%
PA:8=85%
PA:9=90%
Intelliquad FSC-851
(See Note
††
)
AL:1= 3.24% per metre
AL:2= 6.41%
AL:3= 9.51%
AL:4= 9.51% w/ 10 minute
confirmation period
‡‡
AL:5= 12.5% w/ 10 minute
confirmation period
AL:6= Thermal 57°C
PA:1= 3.24%
PA:2= 6.41%
PA:3= 9.51%
PA:4= 9.51% w/ 10 minute
confirmation period
PA:5= 12.5% w/ 10 minute
confirmation period
PA:6= Thermal 57°C
Photo/CO
AL:1=3.24% per metre
AL:2=6.41%
AL:3=9.51%
AL:4=9.51% with a 10 minute
confirmation period
‡‡
AL:5=12.5% with a 10 minute
confirmation period
AL:6=Thermal 57°C
PA:1=3.24%
PA:2=6.41%
PA:3=9.51%
PA:4=9.51% with a 10 minute
confirmation period
PA:5=12.5% with a 10 minute
confirmation period
PA:6=Thermal 57°C
~
Signifies the factory default setting.
Detector Type Alarm (FlashScan) Pre-Alarm
Table C.2 Detector Sensitivity Settings (2 of 2)
