AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015 61
Point Program PrealarmProgram
WALK TEST: This field determines if the output will activate during Walk Test. Values are ON
(the output will activate) and OFF (the output will not activate). Default: OFF.
SWITCH INHIBIT: This field determines whether a user can manually activate an output.
Values are YES (can not be activated manually) or NO (can be activated manually). Default: NO
SILENCEABLE: This field determines whether the user can manually silence an activated output.
Values are as follows:
3.4.3 General Zone
This screen displays when a general zone is chosen at the Point Program menu (see Figure 3.31 on
page 46).
Figure 3.47 Zone Point Programming Screen
NOTE: The following Type ID codes do not participate in Walk Test, and the WALK TEST soft key
will not appear when the screen displays: REL END BELL, RELEASE CKT, REL. FORM C, REL
AUDIBLE, INST RELEASE, NONRESET CTL, TELEPHONE, and FORM-C RESET. The FMM-1
module with SMOKE CONV, HEAT DETECT, or SMOKE DETECT does not participate in Walk
Test.
NO Not manually silenceable
YES - RESOUND FIRE Silenceable, resound on fire alarm events Network and Local Resound
YES - RESOUND SUPERV Silenceable, resound on supervisory events Network and Local Resound
YES - RESOUND FAULT Silenceable, resound for fault Local Resound
YES - NO RESOUND Silenceable, does not resound
NOTE: This soft key will not appear for modules with Type ID codes where silence is not optional.
NOTE: In network applications, specific nodes can be excluded from having the ability to initiate a
resound on the local fire alarm panel. This is programmable via VeriFire Tools. Refer to the VeriFire Tools
help file.
