126 AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015
Type Codes FlashScan Codes
F.6 FlashScan Codes
This section provides a list of FlashScan Codes for FlashScan SLC devices. Select from these codes
to define the type of point:
REL. FORM C
,
N Y N Form-C relay
(SLC only)
n/a Directs relay outputs to perform a releasing function.
RELEASE CKT
,
N Y N NAC (SLC only) n/a Directs outputs to perform a releasing
function.Supervised for open circuits and ground
faults. Short = normal
REL END BELL N Y N NAC n/a Activates NAC audio or visual device when
releasing circuits shut off.
REL AUDIBLE Y Y N NAC n/a Activates audio or visual devices steady when
releasing starts.
FORM C RESET
N Y N Form-C Relay
(SLC only)
n/a Relay module used to interrupt 24V power to four-
wire conventional detectors for 30 seconds upon
reset. Used in conjunction with a monitor module
with a conventional detector Type ID
ECS/MNS GEN N N N NAC n/a Activates NAC mass notification devices when an
MNS event occurs
ECS/MNS STRB N N N NAC n/a Activates strobe mass notification devices when an
MNS event occurs
ECS/MNS SPKR N N N NAC n/a Activates speaker mass notification devices when
an MNS event occurs
ECS/MNS CON N N N NAC n/a Activates control module mass notification devices
when an MNS event occurs
ECS/MNS RELAY N N N Relay n/a Activates relay mass notification devices when an
MNS event occurs
LP PWR SOUND N N N NAC n/a Used to support intelligent loop powered AV devices
AAM SOUNDER Y N Y NAC n/a Used to activate sounder devices when AAM Zone
(CBE position 1) is active.
* Values represent program defaults
With LCM-320 revision 2.0 and higher, this Type Code has external power supervision (FlashScan only). An external power-supervision relay is not required. Note
that Type Codes RELAY, REL FORM C, and FORM C RESET are for use only with FRM-1 modules. Refer to the section on devices requiring external power
supervision in this panel’s installation manual
The FCM-1-REL checks for shorts with all releasing type codes.
Table F.3 SLC Control Module Type Codes (2 of 2)
Label Device/Point
FlashScan Codes
4-20MA FMM-4-20
ACCLIMATE FAPT-751, FAPT-851
BEAM FSB-200,FSB-200S
IQUAD FSC-851,FCO-851
CONTROL FCM-1
FAAST FSA-8000
HEAT FST-751/R, FST-851/R
HIGH HEAT FST-851H
ION FSI-751, FSI-851
LASER FSL-751
MINI/DUAL MONITOR FMM-101,FDM-1
RF PULL STATION FW-MM
RF MONITOR FW-MM
RF GATEWAY FWSG
RF HEAT FWH-200FIX135, FWH-200ROR135
RF PHOTO FWD-200P
RF ACCLIMATE FWD-200ACCLIMATE
MONITOR FMM-1
PHOTO FSP-751,FSD-751P/RP, FSP-851, FSD-751PL/RPL, FSH-751
PHOTO/HEAT FSP-751T, FSP-851T
PHOTO/CO FCO-851
RELAY FRM-1
Table F.4 FlashScan Codes (1 of 2)
