140 AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015
Smoke Control Station Programming Basic Programming: Configurations
Configuration 5 Parameters:
Smoke Control: Non-Latching
Fan Control and Status: 2 fan control modules, using CBE to stop the fan, module to monitor status of the fan
Fan Automation: When fan is in automation, the fan is on. When activated by the CBE, the fan turns off.
Activating the fan start module will turn on the fan. Activating the fan stop module will turn off the fan. The fan status module will
activate then the fan is on and deactivate when the fan is off.
A system reset will turn the fan on.
Duct Detector: Not used.
SCS: FSCS Switch Group Type 8 (CONon, CONoff, VERon)
Configuration 5 Programming:
System Programming
Latching Fire
Mode:
No
Use Single
Start/Stop:
No
Action on CBE: Stop
Point Programming
Smoke Detector: First CBE Zone programmed as Z001 (Fan CBE Zone)
Duct Detector: N/A
Fan Start Point: L01M001
Fan Stop Point: L01M002
Fan Status Point: L01M003
General and Logic Zone Programming:
Fan CBE Zone: Z001, with Non-Resettable Control, Silenceable, and Precedence Participation set to NO
Duct Detector
Zone:
N/A
ZLduct Zone: N/A
ZLstart Zone: ZL301 programmed with the equation NOT(Z001)
ZLstop Zone: N/A
SCS Dip Switch Settings:
Switch 1 Switch 2 Switch 3 Switch 4 Switch 5 Switch 6
Off On On On Off On
SCS Point Programming:
ACS Point 1 ACS Point 2 ACS Point 3
Mode: Control Mode: Control Mode: Monitor
Source: L01M001 Source: L01M002 Source: L01M003
Point Type: Fan Start Point Type: Fan Stop Point Type Fan Status
CBE Zone: ZL301 CBE Zone: Z001 CBE Zone: N/A
