148 AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015
Smoke Control Station Programming Basic Programming: Configurations
Configuration 13 Parameters:
Smoke Control: Non-Latching
Fan Control and Status: Single fan control module, using CBE to stop the fan, module to monitor status of the fan
Fan Automation: When fan is in automation, the fan is on. When activated by the CBE, the fan turns off.
Activating the fan stop module will turn on the fan. De-activating the fan stop module will turn off the fan. The fan status module
will activate then the fan is on and deactivate when the fan is off.
When a system reset is performed, the fan will turn on.
Duct Detector: Not used
SCS: FSCS Switch Group Type 2 (CONoff, VERon)
Configuration 13 Programming:
System Programming
Latching Fire
Mode:
No
Use Single
Start/Stop:
Yes
Action on CBE: Stop
Point Programming
Smoke Detector: First CBE Zone programmed as Z001 (Fan CBE Zone)
Duct Detector: N/A
Fan Start Point: N/A
Fan Stop Point: L01M002
Fan Status Point: L01M003
General and Logic Zone Programming:
Fan CBE Zone: Z001, with Non-resettable Control, Silenceable, and Precedence Participation set to NO
Duct Detector
Zone:
N/A
ZLduct Zone: N/A
ZLstart Zone: N/A
ZLstop Zone: N/A
SCS Dip Switch Settings:
Switch 1 Switch 2 Switch 3 Switch 4 Switch 5 Switch 6
Off Off On On Off On
SCS Point Programming:
ACS Point 1 ACS Point 2 ACS Point 3
Mode: N/A Mode: Control Mode: Monitor
Source: N/A Source: L01M002 Source: L01M003
Point Type: N/A Point Type: Fan Stop Point Type Fan Status
CBE Zone: N/A CBE Zone: Z001 CBE Zone: N/A
