18 AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015
Main Menu and Event Counts Screen Events List Screen
Non-Alarm Events List
The Non-Alarm Events list will be displayed when any event other than an alarm occurs on the fire
panel.
Figure 2.14 Non-Alarm Events List
Refer to the panel’s Operations Manual for a complete description of the Events List display and
operation.
Centre Window: All Non-Alarm events listed, unacknowledged
first, followed by acknowledged, in chronological order.
Top Window: Displays event
selected in Centre window
Total Events Count: Total number of Alarm, Supervisory, Fault, Disable and Other Conditions
FAULT: 1 OF 5
ACKNOWLEDGED FAULT ACM PSI
PSI EXT FLT MONITOR
Module L01M001
10:03:23A TUE 02, DEC, 2014 ACM01P30
MORE INFO...
1 FLT L01M001
Module L01M001
2 FLT L01M002
Module L01M002
3 FLT PSI EXT FLT MONITOR
ALM:0 SUP:0 FLT:5 DIS:0 OTHER:0
11:58:43A TUE 02, DEC, 2014
