AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015 21
Panel Program PrealarmProgram
Soft Keys
NODE NUMBER: Enter the network node number of this panel. For standalone AFP-3030, the net-
work node number will be 000. A valid network node number range is 1-240. Once the soft key has
been pressed, the number may be typed in from the keypad, or the Next/Previous Selection special
function key on the keypad may be used to toggle through online node numbers. The network node
number may be viewed by pressing the Lamp Test special function key longer than five seconds.
(Refer to
Section 5.1, “Version Information”, on page 89.) Default: 000
NODE LABEL: Enter the network node label for this panel. This is the label that appears in the
System Normal message. Default: <blank>
STYLE: Select the wiring style as OPEN or CLOSED. Default: style OPEN
CHANNEL A THRESHOLD, CHANNEL B THRESHOLD: Enter HIGH or LOW, for high or low
threshold setting for channel A or B on the network communications module. Default: HIGH
IP ACCESS: Press this soft key to bring up the IP ACCESS screen.
ACCEPT: Press this soft key to save the information entered on this screen.
IP ACCESS Screen
This screen allows the programmer to set the IP Access. This setting allows the disabling/enabling
of commands, downloads and programming from the Wide Area Network (WAN).
Figure 3.4 IP Access Screen
Soft Keys
IP ACCESS: Press the soft key to scroll through the choices. Press ACCEPT at the desired setting.
Settings are:
ON - IP commands, downloads and programming are allowed.
OFF - IP commands, downloads and programming are NOT allowed. (default)
TIMED - IP commands, downloads and programming are allowed for a two-hour period, after
which the setting will revert to OFF.
NOTE: Enabling IP ACCESS allows downloads over a local area network (LAN) or the internet
(Wide Area Network - WAN) using VeriFire™ Tools through the Noti•Fire•Net™ Web Server
(NWS), or a wide-area enabled NCS through a PC version of Noti•Fire•Net™ Gateway.
Always verify system operation after programming changes are made in this manner.
