90
AFP-3030 Programming Man
ual —
P/N DOC-01-032:A 26/06/2015
Service Screens
Version Information
Figure 5.3 Version Screen 3
Figure 5.4 Version Screen 4
Figure 5.5 Version Screen 5
LCM SOFTWARE VERSION
1 BOOT:
008.000.001 APP: 010.010.002
2 BOOT:
008.000.001 APP: 010.010.002
3 NOT INSTALLED
4 NOT INSTALLED
5 NOT INSTALLED
ACM01: (PSI)001.000.007
ACM02: (ZM )001.000.016
ACM03: NO RESPONSE
ACM04: NOT INSTALLED
ACM05: NOT INSTALLED
ACM06: NOT INSTALLED
ACM07: NOT INSTALLED
ACM08: NOT INSTALLED
ACM09: NOT INSTALLED
ACM10: NOT INSTALLED
ACM11: NOT INSTALLED
ACM12: NOT INSTALLED
ACM13: NOT INSTALLED
ACM14: NOT INSTALLED
ACM15: NOT INSTALLED
ACM16: NOT INSTALLED
ACM17: NOT INSTALLED
ACM18: NOT INSTALLED
ACM19: NOT INSTALLED
ACM20: NOT INSTALLED
ACM21: NOT INSTALLED
ALM22: NOT INSTALLED
ALM23: NOT INSTALLED
ALM24: NOT INSTALLED
ALM25: NOT INSTALLED
ALM26: NOT INSTALLED
ALM27: NOT INSTALLED
ALM28: NOT INSTALLED
ALM29: NOT INSTALLED
ALM30: NOT INSTALLED
ALM31: NOT INSTALLED
ALM32: NOT INSTALLED
