Novatech Bitronics PowerPlex II - Page 18

18
ML0044B December 1, 2017 Copyright 2017 Bitronics, LLC
Physical
Connections Protective
Conductor
Terminal
A #8-32 screw terminal is provided on the AUX PWR terminal block for connection with
protective earth ground. Recommended Torque: 9 In-Lbs, 1.02 N-m
Cable temperature ratin
g
: 85C minimum
Current
(CT)
10-32 Studs for current inputs. Recommended Torque: 12 In-Lbs, 1.36 N-m
Cable temperature rating: 85C minimum
Voltage
(VT) &
(AUX
PWR)
Terminal Block accepts #22-10 AWG (0.35 to 5mm
2
) wire, or terminal lugs up to 0.375"
(9.53mm) wide. Precautions must be taken to prevent shorting of lugs at the terminal block.
A minimum distance of 1/4" (6.3mm) is recommended between uninsulated lugs to maintain
insulation requirements. Recommended Torque: 9 In-Lbs, 1.02 N-m
Cable temperature ratin
g
: 85C minimum
Ethernet RJ45, 8 position modular jack, Category 5 for copper connection; 100m (328 ft.) UTP
(
unshielded twisted pair
)
cable.
Option
Connectors
Display
Port
RJ11, 6 position modular jack, 4 connected (positions 2-5 are used, positions: 1, 6 are not
used); connects remotely through unshielded cable to PPXII-TD Tethered Display (Optional
A
ccessor
y)
. Maximum 30 ft
(
9m
)
IRIG-B
port
BNC connector, connects coax cable with time source (i.e. gps time and frequency receiver)
Serial Port
(extended
chassis
onl
y)
6 position removable terminal block, accepts 26-14AWG solid or 26-12 AWG stranded wire.
Recommended Torque 7 in-lbs, 0.79 N-m.
Digital
Input
(extended
chassis
onl
y)
6 position removable terminal block, accepts 26-14AWG solid or 26-12 AWG stranded wire.
Recommended Torque 7 in-lbs, 0.79 N-m.
Digital
Ouptput
(extended
chassis
onl
y)
9 position removable terminal block, accepts 26-14AWG solid or 26-12 AWG stranded wire.
Recommended Torque 7 in-lbs, 0.79 N-m.
