Weight
(typical)
PowerPlex II: 2.3 lbs (1.04 kg) standard chassis; 3.5 lbs (1.59 kg) in extended chassis (with optional I/O
and serial port)
PPXIITD Tethered Displa
y
(
Optional Accessor
y)
: 0.65 lbs
(
0.30 k
g)
Size PowerPlex II (Figure 2) Standard Chassis: 5.28"H x 5.60"W x 5.63"D – overall depth including handle is
5.75”D (134mm H x 142mm W x 143mm D – overall depth including handle is 146mm D).
Extended chassis (with I/O and serial port): 5.2” H x 8.5” W x 5.9” D (132mm H x 216mm W x 150mm D).
Torque setting for square drive corner screws securing front panel to chassis (4 Places – ground bond): 15
in-lbs (1.7 N-m).
PPXII-TD Tethered Display (Optional Accessory, Figure 4): 4.5”H x 4.5”W x 1.8”D – overall depth. Depth
extends 1.5” behind panel. Allow an additional clearance depth of 2” for RJ11 display connectors and
cable access behind the rear panel of the displa
y
.
