MT 4100 User Guide 25
Mounting and Installing the Device
Prior to performing the installation, ensure that each of the following prerequisites have been met.
l
Engage the services of a qualified Automotive Electronic Installer.
l
Read the entire
MT4100 User Guide
.
l
Perform a basic vehicle functionality check and note any pre-existing issues.
l
Obtain the required cables to connect the device to the vehicle. See the
Accessories
section for
more information.
WARNING! While performing these steps, do not apply excessive force to the retention legs or snap
feature prior to inserting the device as this may deform the mounting bracket.
To mount and install the device:
1. In the chosen location, secure mounting bracket to the mounting surface using one of the
following methods:
l Two (2) # 6 screws (preferred method)
l Double-sided tape
2. After securely attaching the mounting bracket, snap the device into the bracket with the
connector end at the mount opening.
NOTE: You can insert the device with the label side up or down. Position the device so that the
label side has the best unobstructed path to the sky. See notation on the device label.
3. Connect the device to the power source.
